1500N Linear Actuator
5.00 - 15.00 USD ($)/Set
Product Details:
- Product Type Linear Actuator
- Color Silver
- Material Stainless Steel
- Application Industrial
- Click to View more
X
Price And Quantity
- 5.00 - 15.00 USD ($)/Set
- 1 Set
Product Specifications
- Silver
- Linear Actuator
- Stainless Steel
- Industrial
Trade Information
- Shanghai, QINGDAO
- Telegraphic Transfer (T/T), Western Union
- 10000 Set Per Month
- 3-5 Days
- Yes
- PE Bag, Carton and Pallets
- Asia, Australia, Central America, North America, South America, Eastern Europe, Western Europe, Middle East, Africa
- All India
Product Description
Specification Features:
- Input: 12V/24V DC permanent magnet motor
- Max.Load force: 1500 N in push, 1300 N in pull
- Duty cycle: Max 10% or 2 minutes continues works, then 18 minutes not work
- Noise: less than 48dB
- Protection class: IP66
- Ambient temperature: -15 o to +55 o
- Body Materials: Aluminium alloy for outer and inner tube, corrosion resistant
- Certificate: CE, UL, Rohs
- Stroke: 20-1000mm, customize as demands.
- Limited switch: Built-in ( factory preset ).
- Optional function: Hall sensor.
Specification
| Max. push force (N) | Max.pull force (N) | Self-lock (N) | Non-Load Speed (mm/s) | Fully Load Speed (mm/s) | Full Load Current (A) |
| 2000 | 1500 | 2000 | 5 | 3 | 2.2 |
| 1500 | 1300 | 1500 | 6 | 4 | 2.2 |
| 1000 | 800 | 1000 | 11 | 7 | 2 |
| 500 | 500 | 500 | 20 | 13 | 1.8 |
